SD009-PCR-LE/WE
Power Line Disturbance Immunity Testing Software
80,000円 （税込：88,000円）
- Capable of performing compliance testing applied to the IEC61000-4-11, 4-13, 4-14, 4-17, 4-27, 4-28, 4-29, 4-34 or to perform preliminary tests before the standard testing.
- Applied to single-phase/ single-phase three-wire/ three-phase and the DC input power.
- Not only for compliance standard testing, it can be also employed for advance checking in development phases and for margin tests.
- Sequence chain (up to 10 sequences) features improve test efficiency
- Waveform preview provides a general idea of the output wave-form without having an oscilloscope
- The setting condition file and the test result file can be saved in txt or csv format.
List of conformance to the EMC standard tests
The latest standards for IEC61000-4 supported!
SD009-PCR-LE/WE (Product name: Quick Immunity Sequencer 2) is an application software to perform immunity tests based on the standard for power line disturbance in the immunity test standard of EMC (IEC61000-4 series). Not only can it be used for compliance testing based on the latest standards or for some types of preliminary testing, but the software can be also employed for advance checking in development phases and for immunity margin tests, because it allows extended testing conditions to be set as needed.
〇:Conforming as standard △:Partially non-conforming -:Function not available
*Immunity testing for units with 16 A/phase except for those required by IEC61000-4-34
PCR-WEA/WEA2 Series
| standard name | Item | Conforming | |
|---|---|---|---|
| Single phase | Three-phase | ||
| IEC61000-4-11 Voltage dips, short interruptions, and voltage variations | Voltage dip | ✓ *1 | ✓ *1 |
| Short interruption | ✓ *1 | ✓ *1 | |
| Voltage fluctuation | ✓ | ✓ | |
| IEC61000-4-13 Harmonics and interharmonics | Flat curve | ✓ | ✓ |
| Over swing | ✓ | ✓ | |
| Sweep in frequency | ✓ | ✓ | |
| Odd, non multiple of 3 | ✓ | ✓ | |
| Odd, multiple of 3 | ✓ | ✓ | |
| Even harmonics | ✓ | ✓ | |
| Interharmonics | ✓ | ✓ | |
| Meister curve | ✓ | ✓ | |
| IEC61000-4-14 Voltage fluctuation | Voltage swing | ✓ | ✓ |
| Interval | ✓ | ✓ | |
| IEC61000-4-17 Ripple on d.c. input power port | Single-phase rectifier circuit | ✓ | – |
| Three-phase rectifier circuit | ✓ | – | |
| IEC61000-4-27 Unbalance in units | Unbalance | – | ▲ *2 |
| IEC61000-4-28 Variation of power frequency | Frequency variations | ✓ | ✓ |
| IEC61000-4-29 Voltage dips, short interruptions, and voltage variations on d.c. input power port | Voltage dip | ✓ | – |
| Short interruption | ▲ *3 | – | |
| Voltage fluctuation | ✓ | – | |
| IEC61000-4-34 16A/相を超える入力電流の機器のための Voltage drop (dip), instantaneous power failure | Voltage dip | ▲ *4 | ▲ *4 |
| Short interruption | ▲ *4 | ▲ *4 | |
| Voltage fluctuation | ✓ | ✓ | |
*1 Conforms to the standard when used in combination with IEC Dip Simulator DSI series. If using the PCR-WEA/WEA2 alone, the voltage dips and short-time power failures are preliminary tests. *2 110 %, 95.2 %, 93.5 %, 90 %, 87 %, 80 %, 74 %, 71 %, 66 % need to respond to sudden changes of 1 μs to 5 μs. The voltage response of PCR-WEA/WEA2 is more than 40 μs at FAST, which is a preliminary test. *3 Must support output impedance greater than 100 kΩ. The PCR-WEA/WEA2 output impedance is less than 100 kΩ and therefore designed for preliminary testing purposes. Only PCR12000WEA2R conforms to the standards. *4 The device between the range of 16A to 75 A requires having the capability of rapid change with 1 μs to 5 μs. The device exceeding 75 A is not required to have the capability of rapid change with 1μs to 5 μs. (It is relaxed to 1 μs to 50 μs for the device exceeding 75 A.)
PCR-LE/ LE2 Series
| standard name | Item | Conforming | |
|---|---|---|---|
| Single phase | Three-phase | ||
| IEC61000-4-11 Voltage dips, short interruptions, and voltage variations | Voltage dip | ✓ *1 | ✓ *1 |
| Short interruption | ✓ *1 | ✓ *1 | |
| Voltage fluctuation | ✓ | ✓ | |
| IEC61000-4-13 Harmonics and interharmonics | Flat curve | ✓ | ✓ |
| Over swing | ✓ | ✓ | |
| Sweep in frequency | ✓ | ✓ | |
| Odd, non multiple of 3 | ✓ | ✓ | |
| Odd, multiple of 3 | ✓ | ✓ | |
| Even harmonics | ✓ | ✓ | |
| Interharmonics | ✓ | ✓ | |
| Meister curve | ✓ | ✓ | |
| IEC61000-4-14 Voltage fluctuation | Voltage swing | ✓ | ✓ |
| Interval | ✓ | ✓ | |
| IEC61000-4-17 Ripple on d.c. input power port | Single-phase rectifier circuit | ✓ | – |
| Three-phase rectifier circuit | ✓ | – | |
| IEC61000-4-27 Unbalance | Unbalance | – | ▲ *2 |
| IEC61000-4-28 Variation of power frequency | Frequency variations | ✓ | ✓ |
| IEC61000-4-29 Voltage dips, short interruptions, and voltage variations on d.c. input power port | Voltage dip | ✓ | – |
| Short interruption | ▲ *3 | – | |
| Voltage fluctuation | ✓ | – | |
| IEC61000-4-34 Voltage dips, short interruptions, and voltage variations | Voltage dip | ▲ *4 | ▲ *4 |
| Short interruption | ▲ *4 | ▲ *4 | |
| Voltage fluctuation | ✓ | ✓ | |
*1 Conforms to the standard when used in combination with DIP Simulator. If using the PCR-LE/LE2 alone, the voltage dips and short interruptions are preliminary tests. *2 Capability of rapid change with 1 μs to 5 μs is required for 110 %, 95.2 %, 93.5 %, 90 %, 87 %, 80 %, 74 %, 71 %, 66 %. Preliminary test is capable since the voltage response of the PCR-LE/LE2 is 20 μs in FAST mode and 30 μs in MEDIUM mode. *3 Must support output impedance greater than 100 kΩ. The PCR-LE/LE2 output impedance is less than 100 kΩ and therefore designed for preliminary testing purposes. *4 The device between the range of 16 A to 75 A requires to have the capability of rapid change with 1 μs to 5 μs. The device exceeding 75 A does not require to have the capability of rapid change with 1 μs to 5 μs. (It is relaxed to 1 μs to 50 μs for the device exceeding 75 A.)
PCR-WE/WE2 Series
| standard name | Item | Conforming | |
|---|---|---|---|
| Single phase | Three-phase | ||
| IEC61000-4-11 Voltage dips, short interruptions, and voltage variations | Voltage dip | ✓ *1 | ✓ *1 |
| Short interruption | ✓ *1 | ✓ *1 | |
| Voltage fluctuation | ✓ | ✓ | |
| IEC61000-4-13 Harmonics and interharmonics | Flat curve | ✓ | ✓ |
| Over swing | ✓ | ✓ | |
| Sweep in frequency | ✓ | ✓ | |
| Odd, non multiple of 3 | ✓ | ✓ | |
| Odd, multiple of 3 | ✓ | ✓ | |
| Even harmonics | ✓ | ✓ | |
| Interharmonics | ✓ | ✓ | |
| Meister curve | ✓ | ✓ | |
| IEC61000-4-14 Voltage fluctuation | Voltage swing | ✓ | ✓ |
| Interval | ✓ | ✓ | |
| IEC61000-4-17 Ripple on d.c. input power port | Single-phase rectifier circuit | ✓ | – |
| Three-phase rectifier circuit | ✓ | – | |
| IEC61000-4-27 Unbalance | Unbalance | – | ▲ *2 |
| IEC61000-4-28 Variation of power frequency | Frequency variations | ✓ | ✓ |
| IEC61000-4-29 Voltage dips, short interruptions, and voltage variations on d.c. input power port | Voltage dip | ✓ | – |
| Short interruption | ▲ *3 | – | |
| Voltage fluctuation | ✓ | – | |
| IEC61000-4-34 Voltage dips, short interruptions, and voltage variations | Voltage dip | ▲ *4 | ▲ *4 |
| Short interruption | ▲ *4 | ▲ *4 | |
| Voltage fluctuation | ✓ | ✓ | |
*1 Conforms to the standard when used in combination with IEC Dip Simulator DSI series. If using the PCR-WEA/WEA2 alone, the voltage dips and short-time power failures are preliminary tests. *2 110 %, 95.2 %, 93.5 %, 90 %, 87 %, 80 %, 74 %, 71 %, 66 % need to respond to sudden changes of 1 μs to 5 μs. The voltage response of PCR-WEA/WEA2 is more than 40 μs at FAST, which is a preliminary test. *3 Must support output impedance greater than 100 kΩ. The PCR-WEA/WEA2 output impedance is less than 100 kΩ and therefore designed for preliminary testing purposes. Only PCR12000WEA2R conforms to the standards. *4 The device between the range of 16A to 75 A requires having the capability of rapid change with 1 μs to 5 μs. The device exceeding 75 A is not required to have the capability of rapid change with 1μs to 5 μs. (It is relaxed to 1 μs to 50 μs for the device exceeding 75 A.)
Operating environment
- A PC with Microsoft Windows 10 or 11
- 8 GB or more of RAM (16 GB or more recommended)
- 1366×768 dots or higher resolution
- 100 MB or more of free hard disk space (additional space is required to save data)
- CD-ROM drive
- Mouse or other pointing device
- VISA library NI-VISA 5.0.3 or later, Keysight IO Libraries Suite 16.1 or later, or KI-VISA 5.0.5 or later
- USB cable (only when using the USB interface)
- Crossover serial cable (only when using the RS-232C interface)
- LAN cable1 (only when using the LAN interface)
*1 ・PCR-LE
When using the LAN through a HUB: Straight cable
When using the LAN with a one-to-one connection: Crossover cable
If the PC’s LAN port supports Auto-MDIX, either cable can be used for the LAN connection.
・PCR-WE
A straight or crossover cable can be used for the LAN connection because the PCR-WE is equipped with AutoMDIX.
